700C Road Carbon Fiber Bicycle Rim Tubeless Width 25mm Depth 45mm

RD2545 Suitable for road bicycle wheels, Rim type: Tubular, Clincher, Tubeless three options; inner width 18mm, 20mm optional



  • Item No :

    RD2545
  • Warranty :

    2 Years
  • Payment :

    Paypal,TT Bank Transfer
  • Product Origin :

    Xiamen ,China
  • Logo :

    Customized Available
  • Application :

    Road Bicycle
  • Brake System :

    Disc Brake & Rim Brake
  • Material :

    Carbon Fiber T700+T800

700C Road Carbon Fiber Bicycle Rim Tubeless Width 25mm Depth 45mm

.Modle:RD2545

·Size:700C

.Applicable Bicycle:Road Bicycles

.Rim Material:Carbon T700+T800

·Brake Type:Rim brake Or Disc Brake

.Rim Type:Tubeless、Tubular、 Clincher

.Spoke holes:16/18/20/21/24H,Customized Available

.Finishing:UD/3K/12K & Matte/ Glossy

·Inner width:18/20mm

.Outer width:25mm

·Depth:45mm

·ERD:550mm (not including nipple head dimension)

·Weight SL420:±15g  ST:470±15g

·Weight Limit:130kg

·Tyre Pressure:120psi recommended max

·Spoke Hole vertical Angle:7-8° (customized available)

·Spoke Tension:100 ~110kgf (radial) /115 ~130kgf (disc) front, 120~130kgf rear

·Tire:23C~28C  recommended

25mm width carbon road rims info

25mm Wide 30mm Deep 35mm Deep 38mm Deep 40mm Deep 45mm Deep 50mm Deep 55mm Deep 60mm Deep
Super Light Version Weight
Tubular 290±15g 320±15g 330±15g 335±15g 350±15g 360±15g 370±15g 380±15g
Clincher 370±15g 380±15g 390±15g 395±15g 420±15g 440±15g 460±15g 480±15g
Hook Tubeless 370±15g 380±15g 390±15g 395±15g 420±15g 440±15g 460±15g 480±15g
Hookless 370±15g 380±15g 390±15g 395±15g 420±15g 440±15g 460±15g 480±15g
Standard Version Weight
Tubular 330±15g 370±15g 380±15g 385±15g 400±15g 410±15g 420±15g 430±15g
Clincher 420±15g 430±15g 440±15g 445±15g 470±15g 490±15g 510±15g 530±15g
Hook Tubeless 420±15g 440±15g 440±15g 445±15g 470±15g 490±15g 510±15g 530±15g
Hookless 420±15g 440±15g 440±15g 445±15g 470±15g 490±15g 510±15g 530±15g


Features for tubeless type carbon bicycle rims

1,Super light toray 700+toray 800 carbon fiber material combination ,making rims light weight while keeping the performance and stiffness.

2,For tubeless rims ,a rounded edge is designed for easier tire installation.

3,A bump on tubeless rim bed helps to mount tire more efficient.

4,Using special skills to smooth the inside wall,more efficiently cleaning .

5,Scientific drilling spoke angles can be customized according to the needs.
